Yard-Man AF 9150 13AV90YF643 (2010) Mowing deck F (38"/96cm) Ricambi

BRKT:KEEPR:BELT

Nota: Questo articolo è4 volte installato nel dispositivo, il prezzo è per pezzo!
Articolo numero:
783-05497
Posizione:
57
DINNORM:
FINISH:783-05497-Z 783-05497*
Modell Year:
AF 9150 / 2010
non più disponibile
Yard-Man Lawn tractors AF 9150 13AV90YF643 (2010) Mowing deck F (38
PosizioneArticolo numeroDescrizione
1 Yard-Man SPDL ASM:PUL:5.75" DIA618-04474ASPDL ASM:PUL:5.75" DIA
2 631-04312COVER 38" DECK
3 631-04342COVER ASM LEFT
4 631-04343CVR ASM:RIGHT
5 647-04163ROD ASM KEEPER 42" FRENCH COVR
6 683-0254BBRKT:ASM:DECK:HNGR LH LT
7 683-04138BBRAKE ASM:DECK:42"
8 Yard-Man BRAKE ASM:DECK 42"683-04167BRAKE ASM:DECK 42"
9 683-04264BDECK ASM:SD:38" w/WHL BRKTS
10 710-0106HHCS:1/4-20:1.25:GR5:SPEC
11 Yard-Man HHCS:3/8-16:1.75:GR5:STD710-0347HHCS:3/8-16:1.75:GR5:STD
12 Yard-Man SCR:TT:5/16-18:.750:HXINDWSH710-04484SCR:TT:5/16-18:.750:HXINDWSH
13 710-05045SCR:TT:5/16-18:.750:HXINDWSH
14 Yard-Man HHCS:5/16-18:1.25:GR5:STD710-0528HHCS:5/16-18:1.25:GR5:STD
15 Yard-Man SCREW:TT:1/4-20:0.500:HXINDWSH710-0599SCREW:TT:1/4-20:0.500:HXINDWSH
16 Yard-Man SCREW:TT:5/16-18:0.625HXINDWSH710-0604ASCREW:TT:5/16-18:0.625HXINDWSH
17 Yard-Man HEX. SCREW TT:1/4-20:1.500:710-0778HEX. SCREW TT:1/4-20:1.500:
18 Yard-Man SCR:HL:1/4-15:0.750:HXINDWSH710-0895SCR:HL:1/4-15:0.750:HXINDWSH
19 Yard-Man HEX. SCREW B:#10-16:0440:HEX710-0919HEX. SCREW B:#10-16:0440:HEX
20 Yard-Man SCREW HHCS:5/16-18:.75:GR5:STD710-3008SCREW HHCS:5/16-18:.75:GR5:STD
21 Yard-Man HHCS:1/4-20:.75:GR5:STD710-3015HHCS:1/4-20:.75:GR5:STD
22 Yard-Man HHCS:3/8-16:3.50:GR5:STD710-3085HHCS:3/8-16:3.50:GR5:STD
23 Yard-Man FLANGED NUT 5/16-18:GRF:NYLON712-04063FLANGED NUT 5/16-18:GRF:NYLON
24 Yard-Man NUT:FLGLK:1/4-20:GRF:NYLON712-04064NUT:FLGLK:1/4-20:GRF:NYLON
25 Yard-Man NUT:FLGLK:3/8-16:GRF:NYLON712-04065NUT:FLGLK:3/8-16:GRF:NYLON
26 Yard-Man NUT:FLG:5/8-18712-0417ANUT:FLG:5/8-18
27 Yard-Man NUT:FLXLK:1/2-13712-04243NUT:FLXLK:1/2-13
28 712-3006NUT:HEX:1/4-20:GR5
29 Yard-Man PIN:COT:.072 DIA x 1.13 LG714-0104PIN:COT:.072 DIA x 1.13 LG
30 Yard-Man PIN:COT:1/8 x 1.25714-0470PIN:COT:1/8 x 1.25
31 Yard-Man GEAR:DECK:ADJUSTMENT717-04074GEAR:DECK:ADJUSTMENT
32 Yard-Man NUT:SPD:.3125 ID726-0201NUT:SPD:.3125 ID
33 726-0233NUT:PUSH:.25 ID X .50 OD
34 Yard-Man SPR:EXTN:0.75 OD x 6.375LG732-04280BSPR:EXTN:0.75 OD x 6.375LG
35 Yard-Man SPR:EXTN:.500 DIA x 6.375LG732-04287SPR:EXTN:.500 DIA x 6.375LG
36 Yard-Man SPR:COMP:.535 OD x 1.751 LG732-04652SPR:COMP:.535 OD x 1.751 LG
37 734-0973WHEEL:DECK 5.0 X 1.38
38 Yard-Man WASHER:LOCK:5/16:SPLT:REG736-0119WASHER:LOCK:5/16:SPLT:REG
39 736-0211WASHER:FLAT:.285 x 1.250 x.060
40 Yard-Man WASHER:BLVL:.265 x .750 x .060736-0270WASHER:BLVL:.265 x .750 x .060
41 Yard-Man WASH:FLAT:.406 X .875 X.059736-0300WASH:FLAT:.406 X .875 X.059
42 736-0317WASH:BLVL:.630x1.250x.180
43 736-0463WASH:FLAT: .250 x .630 x .052
44 Yard-Man SCR:SHLDR:.496 x 1.525: 3/8-16738-0373SCR:SHLDR:.496 x 1.525: 3/8-16
45 738-04162ASPACER:SHLDR:.8840 x.190
46 738-04166SPACER:SHLDR:.5000 x.1475
47 Yard-Man BLADE:19.30"LG:STAR 3 IN 1:6PT742-0610ABLADE:19.30"LG:STAR 3 IN 1:6PT
48 747-04381BRAKE ROD 38"
49 Yard-Man ROD:DECK 38" EURO COVER747-05061ROD:DECK 38" EURO COVER
50 Yard-Man ROD:HNDL:DECK REL .375 DIA747-1116ROD:HNDL:DECK REL .375 DIA
51 750-04446SPCR:3/8 ID x.68 OD x 1.46 LG
52 Yard-Man SPCR: .260 X .375 X 1.030 LG750-0566ASPCR: .260 X .375 X 1.030 LG
53 Yard-Man BELT:V TYP:A SELECTION X 88.80754-04198CBELT:V TYP:A SELECTION X 88.80
54 Yard-Man PULLEY IDLER756-04129BPULLEY IDLER
55 771-11725ATAG:DNGR:RT-99 CHUTE BLNGL
56 783-04740BRKT:CBL:DECK ENGAGE
57 783-05497BRKT:KEEPR:BELT
58 783-06276BRKT:CVR:FRENCH
59 783-06283PLT:PIVOT:FRNCH CVR:REIGHT
60 783-06284PLT:PIVOT:FRENCH CVR:LEFT
61 783-1025STOP:CHUTE
